Inverter systems play a central role in residential and industrial power setups, converting DC electricity from batteries, solar panels, and other sources into stable AC power for various appliances and equipment. However, in some situations, users may prefer the load to bypass the inverter and be powered directly by the utility grid or a backup source, which is when bypass mode is needed.
Bypass mode is useful not only during inverter maintenance or faults but also for power quality management, overload protection, cost optimization, and temporarily during system commissioning or load testing. In bypass mode, electricity flows directly from the source to the load, bypassing the inverter's internal switches, transformers, and filtering components, ensuring continuous power supply.
This article explores the operation principles of both automatic and manual bypass, scenarios that trigger bypass, and different operating modes (such as UTI, SBU/SOL, and SUB), providing a detailed explanation of inverter bypass procedures and strategies to help users understand system logic and safely manage load power.
What is Inverter Bypass Mode
Inverter Bypass Mode is a critical operational state in power inverter systems where the inverter's normal conversion circuitry is circumvented, allowing electrical power to flow directly from the source to the load without passing through the inverter's DC-to-AC conversion process. This mode essentially creates a direct pathway for electricity, bypassing the inverter's internal switching components, transformers, and filtration systems.
In a typical inverter setup, the device converts direct current (DC) from sources such as solar panels, batteries, or the grid (after AC-to-DC rectification) into alternating current (AC) that powers household appliances and electrical equipment. However, in bypass mode, this conversion process is suspended, and the incoming power from the utility grid is routed directly to the output terminals with minimal or no modification.
Bypass mode serves as both a protective mechanism and a maintenance feature, designed to ensure continuous power supply even when the inverter itself is compromised, overloaded, or requires servicing. It acts as a failsafe that prevents complete power disruption during inverter malfunctions or routine maintenance procedures.
Think of bypass mode as an emergency detour route - when the main road (inverter) is blocked or overwhelmed, traffic (electricity) takes an alternate path to reach its destination (your devices).
Inverter Bypass Mode Operation
Inverter bypass mode can vary depending on the model and application. To better understand how it functions and protects your system, it is important to know that there are two types of bypass: automatic and manual.
Automatic Bypass
The automatic bypass function is based on real-time monitoring, intelligent decision-making, and rapid switching. The system continuously monitors inverter parameters via multiple sensors, including output current, internal temperature, battery SOC, and voltage/frequency. If any parameter exceeds safety limits, the system immediately triggers a bypass command, activating the static transfer switch (SCR or IGBT) to switch to bypass mode within 4–10 milliseconds.
The switching process establishes the bypass before disconnecting the inverter, ensuring that the grid is connected to the load first, and the inverter output is disconnected afterward. This guarantees uninterrupted power to the load.
This mode operates without human intervention and is designed to respond to various abnormal conditions, ensuring continuous power supply and system protection.
-
Scenario 1: Overload Protection
Activated when the output current exceeds the inverter's rated value. The system switches to bypass mode to supply power from the grid and protect the inverter until the load returns to a safe level. -
Scenario 2: Low Battery Protection
Activated when battery SOC falls below the set threshold (typically 10–20%). The system switches to grid bypass to prevent deep discharge and automatically returns to inverter mode after the battery is sufficiently recharged. -
Scenario 3: Internal Fault Protection
When internal hardware faults are detected, the system transfers to bypass mode, logs the fault code, and places the inverter in a protected state requiring repair and manual confirmation before normal operation can resume. -
Scenario 4: Overheat Protection
Occurs when internal temperature exceeds safe limits. The system applies cooling and power reduction measures, switching to bypass mode if necessary, and resumes normal operation once temperatures normalize.
Manual Bypass
Manual bypass is a user-initiated, reversible operating mode. Depending on the inverter design, the bypass function may be integrated into the inverter or implemented through a separately installed external bypass switch (MBS). This mode allows immediate manual intervention when necessary.
-
Scenario 1: Routine Maintenance
Manual bypass is used during scheduled maintenance to safely power down and service the inverter while the load continues to be supplied by the grid. -
Scenario 2: Firmware Upgrade
When firmware updates require inverter restarts, manual bypass ensures uninterrupted power delivery while the inverter is updated and tested. -
Scenario 3: Fault Diagnosis and Repair
Manual bypass allows the inverter to be isolated for detailed diagnostics or component replacement without affecting the load. -
Scenario 4: System Commissioning and Testing
During initial system commissioning, manual bypass enables comprehensive testing of the inverter under various load conditions before normal operation begins.
How to Enable Inverter Bypass Mode
The inverter's automatic bypass function is enabled by default. Its operation can also be adjusted by setting specific trigger values according to the priority of different power sources. The following three modes illustrate how the inverter system manages power from the utility, solar, and battery under different conditions.
Utility-First Output Mode (UTI)
In UTI mode, the system prioritizes solar power to supply the load while keeping the grid online to provide minimal current for anti-backfeed protection and reactive power support.
When solar power is sufficient, it first meets the load demand and then charges the battery. When solar power is insufficient, it prioritizes compensating for the battery drain caused by the inverter's internal components, with remaining solar power supporting the load and any shortfall supplemented by grid power.
The battery serves as backup - the inverter only switches operating modes when the grid fails or operates outside acceptable parameters, converting energy from the solar panels and battery through the inverter circuit to supply AC power to the load.
SBU/SOL Mode
In SBU mode, system operation can be controlled by setting the battery's operating voltage range. When there's no solar input or insufficient solar power to meet load demand, the battery primarily supplies power to prevent solar power fluctuations from affecting the load.
This continues until the battery voltage drops to the preset discharge lower limit (item 04), at which point the inverter automatically switches to bypass mode and grid power supplies the load.
Subsequently, charging from both solar and grid power raises the battery voltage back to the upper limit of the operating range (item 05), causing the system to exit bypass mode and resume battery-powered operation.
SOL Mode
Similar to SBU, when solar power cannot fully meet load demand, the battery assists until its voltage falls below the preset discharge lower limit (item 04), triggering the inverter to switch to bypass mode with direct grid power supply to the load.
The key difference is that when there's no solar input, regardless of whether the battery has discharged to the minimum voltage setting, the inverter immediately switches to grid bypass mode to power the load and charge the battery. When solar input resumes, the system exits bypass mode.
SUB Mode
In SUB mode, solar power prioritizes battery charging while simultaneously powering the load alongside grid power, provided there's remaining solar capacity. When solar power is insufficient, it prioritizes battery charging while grid power independently supplies the load.
Without solar input, grid power both supplies the load and charges the battery. Only when grid power is unavailable does the battery supply power to the load through the inverter.
