Inverter mode	Nominal output voltage RMS	120VAC (100~120VAC 5V Gear setting)
	Output frequency	50HZ±0.3HZ or 60HZ±0.3HZ
	Output waveform	Pure Sine wave
	Output overload	105% < Load <120% ±10%: Fault(tum off output after 10 seconds) 120% < Load < 150% ±10%: Fault (turn off output after 3 seconds) 150%> Load ±10%: Fault (turn off output after 1 seconds)
	Short circuit protection	Software protection
	Nominal efficiency	>88%
	Power factor	0.9-1
Line mode	Input voltage range	Narrow range		Wide range
		Nominal output voltage±15%		Nominal output voltage +15%, -23%
	Input frequency voltage	40Hz-70Hz
	Input wave form	Sine wave(Utility or generator)
	Short circuit protection	Circuit breaker
	Output Overload	120%> Load <150%±10%: fault (turn off output after 60 seconds); 150%> Load ±10%: fault(tum off output after 1 seconds)
	Over Charge protection shutdown	16.0 for 12V dc
	Efficiency online transfer mode	>95%
	AC Charge	Charge current can be set (5A UP/DOWN setting, For specific parameters, please refer to Appendix)
Selection of battery charging Voltage type
Battery type	Fast V		Float V
Gel U.S.A	14		13.7
A.G.M 1	14.1		13.4
A.G.M 2	14.6		13.7
Sealed Lead Acid	14.4		13.6
Gel Euro	14.4		13.8
Open Lead Acid	14.8		13.3
Calcium	15.1		13.6
Desulphation	15.5 for 4 hrs then off
Li	14.7
other	User-defined
Charge Current	65A
Battery	Nominal DC Input Voltage	12V
	Battery voltage range	12V(10Vdc ~16Vdc) ±0.3Vdc
	Low DC Warning Voltage	12V(10.5Vdc ± 0.3Vdc )
	Low DC Cut-off Voltage	12V(10Vdc±0.3Vdc )
