SKU: POW-M60-ULTRA

60A MPPT Solar Charge Controller for Parallel

Sale price$149.00 USD Regular price$159.00 USD
Save 6%

01

High-Efficiency Charging

Innovative MPPT technology with a tracking efficiency of up to 99.9% and a peak conversion efficiency of up to 98.1%, reducing power consumption, minimizing heat generation, and lowering operating temperatures. MPPT technology tracks the maximum power point voltage (Vmp) of the array as it varies with weather conditions, ensuring the collection of maximum power from the array throughout the day.

02

Customizable Charging Current Limit

Different types of batteries have varying requirements for charging current. Customizing the charging current limit ensures that the charge controller is compatible with multiple battery types. By setting a maximum charging current, you can prevent excessive charging rates, thereby reducing potential damage to the battery and extending its lifespan. The configurable range for the charging current is 2 to 60A.

03

Multiple Electronic Protections

Features an internal cooling fan for forced air cooling and an external heat dissipation plate for natural heat dissipation, enhancing overall equipment efficiency. This MPPT solar charge controller offers comprehensive protection against PV short circuit, reverse polarity, battery overvoltage, overdischarge, load overcurrent, load short circuit, and over-temperature conditions to keep your system safe at all times.

Solar charge controller three stage charging
04

Adaptive Boost Charging

During the initial charging phase, adaptive boost charging monitors battery response and automatically determines the duration of the boost stage for each independent charging cycle, ensuring that the battery is fully charged at any discharge level or capacity while avoiding overcharging during the boost charging stage (extends battery life).

05

Up to 12 Units in Parallel

The parallel operation function allows for easy expansion of the solar panel configuration and energy storage capacity limits, thus increasing the scale of energy storage. Support up to 12 charging in parallel to expand the system and meet different monitoring requirements, so that can be widely used for various applications, e.g. solar RV, household systems, and field monitoring.
01

High-Efficiency Charging

Innovative MPPT technology with a tracking efficiency of up to 99.9% and a peak conversion efficiency of up to 98.1%, reducing power consumption, minimizing heat generation, and lowering operating temperatures. MPPT technology tracks the maximum power point voltage (Vmp) of the array as it varies with weather conditions, ensuring the collection of maximum power from the array throughout the day.

02

Customizable Charging Current Limit

Different types of batteries have varying requirements for charging current. Customizing the charging current limit ensures that the charge controller is compatible with multiple battery types. By setting a maximum charging current, you can prevent excessive charging rates, thereby reducing potential damage to the battery and extending its lifespan. The configurable range for the charging current is 2 to 60A.

03

Multiple Electronic Protections

Features an internal cooling fan for forced air cooling and an external heat dissipation plate for natural heat dissipation, enhancing overall equipment efficiency. This MPPT solar charge controller offers comprehensive protection against PV short circuit, reverse polarity, battery overvoltage, overdischarge, load overcurrent, load short circuit, and over-temperature conditions to keep your system safe at all times.

04

Adaptive Boost Charging

During the initial charging phase, adaptive boost charging monitors battery response and automatically determines the duration of the boost stage for each independent charging cycle, ensuring that the battery is fully charged at any discharge level or capacity while avoiding overcharging during the boost charging stage (extends battery life).

05

Up to 12 Units in Parallel

The parallel operation function allows for easy expansion of the solar panel configuration and energy storage capacity limits, thus increasing the scale of energy storage. Support up to 12 charging in parallel to expand the system and meet different monitoring requirements, so that can be widely used for various applications, e.g. solar RV, household systems, and field monitoring.

Solar charge controller three stage charging

Solar Controller

Product specification

Important Notice: Please Read Product Manual Before Buying. Detailed specifications and features provided. Contact our support team for assistance. Thank you for choosing us.

Model

POW-M60-ULTRA

Nominal System Voltage (V)

12/24/36/48

Rated Charging Current (A)

60

12V System (W/V)

720/20~80

24V System (W/V)

1440/37~105
