Wiring Batteries in Series vs Parallel in Solar Power System

batteries in series vs parallel

In the world of solar power systems, the configuration of batteries is a critical factor influencing overall performance. The decision to wire batteries in series or parallel, or a combination of both, significantly impacts the efficiency and longevity of the system. This comprehensive guide explores the intricacies of these options.

Wiring Batteries in Parallel

To wire batteries in parallel, the positive terminals are connected together, as are the negative terminals. This configuration keeps the voltage constant, while the overall capacity (Ah) increases.

diagram of batteries in parallel

How many batteries can I wire in parallel

In theory, the number of batteries you can wire in parallel is unlimited. However, practical considerations, such as available space, maintenance accessibility, and the system's specific requirements, need to be taken into account.

Advantages of wiring batteries in parallel

Increased Capacity(Ah)

Connecting batteries in parallel increases the total capacity while keeping the voltage of the battery system constant, extending the system's power supply duration.

For example, if you have two 12V 100Ah batteries connected in parallel, the total capacity becomes 200Ah. The voltage remains the same, but the working duration of the batteries is doubled.

Fault Tolerance

If one battery in parallel fails, the others can continue operating, reducing the risk of system failures.


Imbalanced charging and discharging may occur if a specific battery within a parallel group fails, posing a risk of diminished overall battery life.

To mitigate this, regularly monitor the health of each battery in parallel and ensure they are of similar age, capacity, and chemistry. Implement a robust battery management system (BMS) to prevent overcharging or over-discharging of individual batteries.

Disadvantages of wiring batteries in parallel

Increased Charging Time

In parallel-connected batteries, the enlarged capacity of the battery array often results in the need for extended charging periods.

Increased Losses and Cable Expenses

In comparison to batteries arranged in series, achieving equivalent power output with parallel-connected batteries necessitates a higher current due to the lower system voltage. The higher current demands the use of larger diameter cables to reduce internal resistance and, consequently, lower voltage drop. However, larger diameter cables can be more expensive.

Wiring Batteries in Series

Connecting batteries in series involves linking the positive terminal of one battery to the negative terminal of the next. This arrangement increases the total voltage, and for example, connecting two 12V 100Ah batteries in series results in a 24V system.

diagram of batteries in serires

How many batteries can I wire in series

The maximum number of batteries that can be connected in series is generally determined by the battery type and manufacturer specifications.

For instance, the PowMr 12V 100Ah battery allows series connections of up to 4 units. Please refer to the product manual or contact the manufacturer for detailed information.

Advantages of wiring batteries in series

Increased Voltage

By connecting four 12V 100Ah LiFePO4 batteries in series, a robust 48V system is achieved without sacrificing overall capacity. This configuration maintains a 100Ah capacity, showcasing the versatility of series wiring.

Enhanced Efficiency in Power Transmission

The boost in system voltage resulting from series wiring translates to a reduction in system current. This, in turn, enables the utilization of thinner wiring, leading to improved efficiency in power transmission and minimizing voltage drop within the system.

Charging Efficiency Amplified

Series wiring proves advantageous in the charging process, exemplified by the performance of an MPPT solar charge controller.

A 60A solar charge controller at 12V can handle 720 watts of solar, but at 24Vx60A, it efficiently manages up to 1440 watts. This underscores the substantial benefits of employing series-wired batteries in larger power systems, especially at higher voltages.

Disadvantages of wiring batteries in series

Fixed Series Capacity

When batteries are connected in series, the total voltage increases while the total capacity (in ampere-hours, Ah) remains the same. This means that the overall energy storage capacity doesn't change when batteries are connected in series.

Charging Imbalance

One significant disadvantage of wiring batteries in series is the potential for charging imbalances. Due to differences in internal resistances or variations in the state of charge, individual batteries may charge at different rates.

Elevated Voltage Application Limitations

Performing this action requires all your applications to operate at an elevated voltage. For instance, when you link two 12V batteries in series, the resulting voltage is 24V. Without employing a converter, you won't be able to supply power to any 12V appliances in this setup.

Reduced Redundancy

If one battery in a series configuration fails or drops in capacity significantly, it can impact the entire battery bank, affecting the overall performance of the connected devices or the entire system.

Solar Batteries in series-parallel connection

You can connect batteries in series and parallel, which is often done to meet specific voltage and capacity requirements in a solar power system.

Connecting batteries in series involves linking the positive terminal of one battery to the negative terminal of the next, cumulatively increasing voltage. For parallel connections, link positive terminals together and negative terminals likewise, boosting overall capacity. Ensure consistency in battery type and capacity within each series or parallel group.

diagram of batteries in series-parallel connection

To illustrate, consider a setup with eight 12V 100Ah LiFePO4 batteries. Two pairs are connected in parallel, resulting in four parallel groups. These groups are then connected in series, creating a 24V system with a total capacity of 400Ah.


Typically, the initial step involves connecting batteries in series, followed by parallel wiring as the second step. Both methods are viable, but prioritizing series connections over parallel ones enhances safety.

Is it better to wire batteries in parallel or series?

When determining the optimal wiring configuration, various factors must be considered. The table below summarizes the advantages and disadvantages of wiring batteries in series or parallel:

Aspect Parallel Wiring Series Wiring Both (Series and Parallel)
Voltage Constant (e.g., 12V) Increased (e.g., 24V) Increased, Depending on Configuration
Capacity Increased Reduced Balanced Combination
Simplicity High High Moderate
Expansion Easy May require additional considerations Flexible and Scalable

Tips of Solar Batteries Connection

Connecting solar batteries involves several considerations to ensure a safe and efficient setup. Here are some tips for connecting solar batteries:

Battery Selection

It is important to ensure that all batteries used in a series/parallel configuration are of the same type and the same age, have the same capacity and voltage, and are properly balanced to prevent overcharging or discharging of individual batteries. Lead-acid and lithium-ion batteries are common types of solar batteries for inverter. Consider factors like capacity, voltage, and cycle life.

Charge Controller and Inverter Compatibility

Adjust charge controller settings based on battery manufacturer recommendations, covering absorption voltage, float voltage, and temperature compensation. Ensure inverter compatibility with battery bank voltage and type, noting specific connection requirements.

Cable Sizing

Use appropriately sized cables to connect batteries. Undersized cables can lead to voltage drops and reduced system efficiency. Refer to a cable sizing chart of the product manual based on the current and distance.

Temperature and Ventilation

Install batteries in a well-ventilated area, and consider venting systems if necessary. Additionally, batteries perform optimally within a specific temperature range. Avoid exposing them to extreme temperatures, and consider temperature-compensated charging if your charge controller supports it.

Fusing and Circuit Protection

Install appropriate fuses and circuit breakers to protect the battery bank from overcurrent and short circuits. Place fuses on both the positive and negative sides of the battery bank.

Always refer to the manufacturer's guidelines and specifications for the specific batteries and components you are using in your solar power system. Additionally, local electrical codes and regulations should be followed during installation. If you are unsure or uncomfortable with the installation process, consider hiring a professional to install and connect the solar batteries. This can help avoid mistakes and ensure a safe and efficient system.
