PowMr 40A MPPT Solar Charge Controller HHJ-40A

$8999
Out of stock

Minimum quantity for "PowMr 40A MPPT Solar Charge Controller HHJ-40A" is 1.

Why PowMr?
  • — Fast Delivery
  • — 24 months warranty
  • — Avg. response time 1 Hrs. (Working  Day)
  • PowMr Everywhere
    Wholesale

    PowMr UK warehouse,AUS warehouse,USA warehouse,GER warehouse and China warehouse

    BrandPowMr Lithium Battery Activation No Lithium Batteries Activation Battery Voltage12V, 24V, 36V, 48V Battery TypeFlooded Batteries, Gel Batteries, Lead-acid Batteries, AGM Batteries Charging Current40 Amps Ground TypeNetagive Ground Solar Panel Max Input Power1040W-2500W Solar Panel Max Input Voltage150V WarehouseUSA Warehouse, AUS Warehouse, GER Warehouse

    PowMr 40A MPPT Solar Charge Controller 12V 24V 36V 48V Auto Solar Regulator with LCD Display MPPT-40A

    Warming tips:

    Make sure the Voc of PV meets the requirement as right. VOC is 1.5 times of Battery voltage will be the best efficiency

    • Brand: PowMr
    • Product Model: HHJ-40A
    • 100% MPPT controller Intelligent, Max efficiency ≥98.1%, PV utilization ≥99%
    • Built-in DSP controller with high-performance Automatic battery voltage detection 12V/24V/36V/48V
    • Battery options: Vented, Sealed, Gel, NiCd, Lithium battery. Dynamic large icon display PV and Battery status, working mode: Night mode, no charging, MPPT mode, Absorption mode, Floating mode, and troubleshooting prompts.
    • Excellent heat dissipation protection: Intelligence Fan-on temperature >45℃
    • Large four big buttons, easy to use, more conveniently.

    MPPT-40A Warming tips: Make sure the Voc of PV meets the requirement as right. VOC is 1.5 times of Battery voltage will be the best efficiency.


    Feature:

    *Charging 3-stage:constant current(MPPT), constant voltage(Absorption Voltage), floating charge
    *Selectable battery type Vented/ Sealed / Gel / NiCd / Lithium battery (default is Sealed) (defined voltage for other battery by user)
    *Soft start time ≤1S
    Dynamic response and recovery time 100us
    Max efficiency ≥98.1%
    *PV utilization ≥99%

    Input specification:
    12V system: DC20V~DC80V
    24V system: DC37V~DC105V
    36V system: DC50V~DC160V
    48V system: DC72V~DC160V

    The maximum PV input voltage (Voc): DC190V
    (The controller can’t work at this voltage of long duration that will break the controller. Please refer to the Input voltage from PV.)

    The maximum PV input power
    (The total power rate of PV can’t be over this watt that will break the controller.)
    12V system (480W) ;
    24V system (960W) ;
    36V system (1400W);
    48V system (1700W) ;

    Output specification

    Overcharging protection voltage:
    12V system (15V);
    24V system (30V);
    36V system (45V);
    48V system (60V);

    Air circuit breaker and wires requirement

    copper wires:9AWG
    air circuit:63A

    Notes: The output terminal is for lamp only ( 12V system less 60W, 24V/36V/48V system less 100W ), and it will be burnt if connecting to other loads. The output for the battery is no polarity reverse protection.

    Package including:

    1XMPPT 40amp Solar Charge Controller
    1XEnglish Manual



    type  POW-30AH-12.8V POW-50AH-12.8V POW-100AH-12.8V
    Nominal voltage 12.8V 12.8V 12.8v
    Rated capacity 30Ah(0.2C/25)℃(Min:29Ah) 50Ah(0.2C/25)℃(Min:49Ah) 100Ah (0.2C/25°C) (Min:96Ah)
    Operating voltage range 10V-14.6V(Typical:12.8V) 10V-14.6V(Typical:12.8V) 10V~14.6V (Typical:12.8V)
    Charging voltage 14.6V 14.6V 14.6v
    Dischange cut -off voltage  10V 10V 10v
    Charging current(Max) 15A  25A  50A
    Dischange current (Max) 30A 50A 100A
    Length 195mm 228mm 325mm
    Width 133mm 138mm 170mm
    Height 171mm 210mm 215mm
    Weight about 4.5kg about 6.2kg About 11.5kg
    Shell Plastics/Black Plastics/Black Plastics/Black
    Series Maximum support for 4 sets in series Maximum support for 4 sets in series Maximum support for 4 sets in series
    Parallel support support Support
    Alarm&potection Over Voltage ,Under Voltage ,Over Current,Short Circuit,etc Over Voltage ,Under Voltage ,Over Current,Short Circuit,etc Over Voltage, Under Voltage, Over Current, Short Circuit etc.
    Cooling mode  Automatic cold and hot  Automatic cold and hot  Automatic cold and hot
    Terminal stud M6 M8 M8
    Altitude ≤4000m ≤4000m <4000m
    Recommended operating charge temperature  15℃-40℃ 15℃-40℃ 15%~85%
    Recommended operating dischage temperature 15℃-40℃ 15℃-40℃ 0°C~50°C
    Recommended operating storagetemperature -20℃-45℃ -20℃-45℃ -10°C~60°C
    Humidity 15%-85% 15%-85% 15°C~40°C
    Operating Charge temperature 0℃-50℃ 0℃-50℃ 15°C~40°C
    -10Operating Dischage temperature -10℃-60℃ -10℃-60℃  -20°C~45°C

    User Manual (PowMr_MPPT_30-60A_User_Manual.pdf, 902 Kb) [Download]
