6200W 220Vac 48Vdc All In One Inverter Charger Supports 9 Units in Parallel

SKU: POW-HVM6.2KP

6200W 220Vac 48Vdc All In One Inverter Charger Supports 9 Units in Parallel

Name: 6200W 220Vac 48Vdc All In One Inverter Charger Supports 9 Units in Parallel
Brand: PowMr
SKU: POW-HVM6.2KP
Price: 509.00 USD
Availability: InStock

$509.00 USD

$649.00 USD

Save 22%

4.0

Quantity:

Overview

6200W Solar Inverter

6.2kW pure sine wave inverter converts 48Vdc to 220Vac efficiently, delivering stable, clean power suitable for sensitive electronics, ensuring smooth operation and reliable performance in both residential and commercial setups.

Integrated 120A MPPT Controller

Integrated 120A MPPT supports 48V systems, compatible with Gel, AGM, SLA, FLD, LiFePO4, and lithium batteries. Voltage range 60V-500V maximizes solar energy harvest, enhancing battery life and system efficiency under varying sunlight conditions.

Up to 9 Units in Parallel Connection

Supports up to 9 units in parallel, operating in single-phase or three-phase modes. Expandable system design allows high-capacity setups, providing reliable power for large loads and scalable energy solutions without complex rewiring.

Advanced System Protection

Comprehensive safeguards protect against overvoltage, undervoltage, overcurrent, short circuit, and overheating. RS232 and RS485 communication ensures seamless monitoring and reliable operation for stable energy supply and long-term durability.

Flexible Output and Charging

Two output modes (SUB, SBU) and three charging strategies (solar first, hybrid, solar only) offer versatile energy management, optimizing battery charging and usage according to energy availability, load demand, and user preferences.

Specifications

Model

POW-HVM6.2KP

Rated Load Power (W)

6200

Ac Out Put (V)

220 (±5% Ajustable)

DC Out Put (V)

48

Phase

Single Phase, Three Phase (in Parallel Connection)

FAQs

Can the 6.2kW solar inverter be used in a three-phase system with parallel connections?

Yes, the 6.2kW solar inverter is designed to support three-phase systems through parallel connections. It is required to have at least 3 inverters or maximum 9 inverters to support three phase equipment. It's required to have at least one inverter in each phase or it's up to four.

Can I mix different solar panel models with this inverter?

It is highly discouraged for panels on the same MPPT input string. Using panels of different make, model, or wattage on the same MPPT input string is strongly discouraged. All panels in a series string should be identical to prevent significant power loss, as output is limited by the lowest-performing panel. For mixed panels, use an inverter with separate MPPT inputs or parallel operation capability.

What is the correct order to connect my solar system?

When installing a solar power system, connect components in this order:
1) Batteries,
2) Charge controller/inverter charger
3) Solar panels (to PV input)
4) Inverter/AC loads
Always verify polarity, voltages, and wire sizing for safety.
When disconnecting, reverse the order.
