| Technical Specification for Selection Guide: POW-LIO-4810 | |||
| MODEL | POW-LIO-4805 | POW-LIO-4810 | POW-LIO-4805-W |
| Array Mode | 16S | ||
| Nominal Energy(KWh) | 5 | 10 | 5 |
| minimum energy(KWh） | ≥4.92 | ≥10 | ≥4.92 |
| Nominal Voltage(V) | 51.2 | ||
| charge voltage(V) | 58.4 | ||
| Discharge Cut-off Voltage(V) | 40 | 40 | 40 |
| Standard Charging Current(A) | 50 | 50 | 20 |
| Max.Continuous Charging Current(A) | 100 | ||
| Max.Continuous Discharging Current(A) | 100 | ||
| Cycle Life | ≥4000times@75%DOD,25℃ | ||
| Communication Mode | RS485 | RS485 | RS485 |
| operating temp. | Charging：0~60℃ | Charging：0~60℃ | Charging：0~60℃ |
| Discharging：-20℃~65℃ | Discharging：-20℃~65℃ | Discharging：-20℃~65℃ | |
| Product Size(L×W×H)mm | 750x149x511 | 780x208x606 | 470x145x770 |
| Product Net Weight(Kg) | ~65 | ~98 | ~55 |
| Package Size(L×W×H)mm | 840x610x305 | 870x670x360 | 580x220x880 |
| Product Gross Weight(Kg) | ~82.5 | ~115 | ~63 |
| Note | Supportupto15pcsinparallel | ||
| Accessories: | Matchedbattery'sconnector with wiring | Accessories: 1. Walled-mounted bracket 2. Mounting screws 3. Matched battery connector with wiring | |
