Technical Specification for Selection Guide: POW-LIO-4810 | |||
MODEL | POW-LIO-4805 | POW-LIO-4810 | POW-LIO-4805-W |
Array Mode | 16S | ||
Nominal Energy(KWh) | 5 | 10 | 5 |
minimum energy(KWh) | ≥4.92 | ≥10 | ≥4.92 |
Nominal Voltage(V) | 51.2 | ||
charge voltage(V) | 58.4 | ||
Discharge Cut-off Voltage(V) | 40 | 40 | 40 |
Standard Charging Current(A) | 50 | 50 | 20 |
Max.Continuous Charging Current(A) | 100 | ||
Max.Continuous Discharging Current(A) | 100 | ||
Cycle Life | ≥4000times@75%DOD,25℃ | ||
Communication Mode | RS485 | RS485 | RS485 |
operating temp. | Charging:0~60℃ | Charging:0~60℃ | Charging:0~60℃ |
Discharging:-20℃~65℃ | Discharging:-20℃~65℃ | Discharging:-20℃~65℃ | |
Product Size(L×W×H)mm | 750x149x511 | 780x208x606 | 470x145x770 |
Product Net Weight(Kg) | ~65 | ~98 | ~55 |
Package Size(L×W×H)mm | 840x610x305 | 870x670x360 | 580x220x880 |
Product Gross Weight(Kg) | ~82.5 | ~115 | ~63 |
Note | Supportupto15pcsinparallel | ||
Accessories: | Matchedbattery'sconnector with wiring | Accessories: 1. Walled-mounted bracket 2. Mounting screws 3. Matched battery connector with wiring |
