5KW 48V Inverter/Charger And MPPT Solar Charger Pure Sine Wave Hybrid Inverter Charger with Parrallel funciton POW-MKS III-5K-48V-P

Write a review
Ask a question
POW-MKS III-5K-48V-P
In stock
BrandPowMr Lithium Battery Activation No Lithium Batteries Activation Battery Voltage48V Battery TypeLithium Batteries, Flooded Batteries, AGM Batteries, User Mode Inverter TypeHigh frequency Inverters Load workout with Battery Parallel Function PhaseSingle Phase, Parallel Single for Three Phase AC output230Vac±5% Rated Load Power5000W Max Panel Input Volt450V-500V PV Terminal Charging Modebuild-in MPPT Solar Charge Controller Max Solar Panel Input Power5000W AC Charging Current100 Amps PV Charging Current100amps AC+PV Charging Current100Amps Wifi/Bluetooth ModuleWifi Module(Optional)
$1,09900
$89900
You save: $200.00
Why PowMr?
  • — 24 months warranty
  • — Fast Delivery
  • — Free Shipping
  • — Avg. response time 1 Hrs. (Working  Day)
  • PowMr Everywhere
Wholesale

PowMr Hybrid Inverter Charger, POW-MKS III-5K-48V-P with inverter/charger with MPPT solar charger

Product Description:

The device has an integrated MPPT solar charge controller of one to two weights. It can accept the possible photovoltaic voltage, allows various photovoltaic modules to be connected, avoids the use of combiner boxes, and reduces installation costs.

Product Features:

• Compatible with Lithium batteries
• Integrated high-voltage MPPT charge controller(s).
• Integrated AC battery charger
• Up to 9 inverters can be connected in parallel, 3-phase or split-phase for up to 58.5 kW of synchronized AC power
• Galvanic isolation of battery allows positive or negative grounding of the same
• Datalogger with up to 60 days of data storage
• Charge controller(s) function(s) even if inverter is turned off to keep batteries fully charged
• Functions even without an expensive battery to reduce energy consumption from the grid with minimal investment
• Detachable display / communication unit with 6 LEDs and an intuitive LCD screen
• High level of connectivity: BLE, USB-OTG (on-the-go), CAN Bus, RS-485, RS-232, relay for generator start
• Integrated buzzer for error indications
• Washable filter reduces dust buildup in the inverter
• Grid feed-in option is code-protected to avoid accidental feed-in

Introduction:

This inverter can be used in parallel with two different operation modes.
1. Parallel operation in single phase with up to 9 units. The supported maximum output power is 45KW/45KVA.
2. Maximum nine units work together to support three-phase equipment. Seven units support one phase maximum. The supported maximum output power is 45KW/45KVA and one phase can be up to 35KW/35KVA.

Package Listing:

  • Inverter---1pcs;
  • Clamp Sensor---1pcs;
  • Power Cable---1pcs
  • English Manual--1pcs;
  • Wifi(Optional)

Parallel Operation in Single phase



Please read the specification carefully before install

Table 2 Inverter Mode Specifications

INVERTER MODEL

5KW

Rated Output Power

5KVA/5KW

Output Voltage Waveform

Pure Sine Wave

Output Voltage Regulation

230Vac±5%

Output Frequency

60Hz or 50Hz

Peak Efficiency

90%

Overload Protection

                           5s@≥150% load; 10s@110%~150% load

Surge Capacity

2* rated power for 5 seconds

Nominal DC Input Voltage

48Vdc

Cold Start Voltage

46.0Vdc

Low DC Warning Voltage



@ load < 20%
@ 20% ≤ load < 50%
@ load ≥ 50%

44.0Vdc
42.8Vdc
40.4Vdc

Low DC Warning Return Voltage



@ load < 20%
@ 20% ≤ load < 50%
@ load ≥ 50%

46.0Vdc
44.8Vdc
42.4Vdc

Low DC Cut-off Voltage



@ load < 20%
@ 20% ≤ load < 50%
@ load ≥ 50%

42.0Vdc
40.8Vdc
38.4Vdc

High DC Recovery Voltage

64Vdc

High DC Cut-off Voltage

66Vdc

Brand information
Brand :
PowMr
Battery Information for inverters and controllers
Lithium Battery Activation :
  • No Lithium Batteries Activation
Battery Voltage :
  • 48V
Battery Type :
  • Lithium Batteries
  • Flooded Batteries
  • AGM Batteries
  • User Mode
Inverter Information
Inverter Type:
  • High frequency Inverters
Load workout with Battery:
Yes
Parallel Function:
Yes
Phase:
  • Single Phase
  • Parallel Single for Three Phase
Split Phase:
No
AC output:
  • 230Vac±5%
Rated Load Power:
  • 5000W
Solar Panel Information for inverters
Max Panel Input Volt :
  • 450V-500V
PV Terminal Charging Mode:
  • build-in MPPT Solar Charge Controller
Max Solar Panel Input Power:
  • 5000W
Charging Current Information for inverters
AC Charging Current:
  • 100 Amps
PV Charging Current:
  • 100amps
AC+PV Charging Current:
  • 100Amps
Accessories information for inverters
Wifi/Bluetooth Module:
  • Wifi Module(Optional)
