Inversor Todo en Uno 6500W 220Vac 48Vdc Compatible con 9 Unidades en Paralelo

SKU: POW-HVM6.5KP

Inversor Todo en Uno 6500W 220Vac 48Vdc Compatible con 9 Unidades en Paralelo

Name: Inversor Todo en Uno 6500W 220Vac 48Vdc Compatible con 9 Unidades en Paralelo
Brand: PowMr
SKU: POW-HVM6.5KP
Price: 509.00 USD
Availability: InStock

$509.00 USD

$719.00 USD

Ahorra 29%

Cantidad:

Resumen

6500W Solar Inverter

6.5kW pure sine wave inverter converts 48Vdc to 220Vac efficiently, delivering stable, clean power suitable for sensitive electronics, ensuring smooth operation and reliable performance in both residential and commercial setups.

Integrated 120A MPPT Controller

Integrated 120A MPPT supports 48V systems, compatible with Gel, AGM, SLA, FLD, LiFePO4, and lithium batteries. Voltage range 60V-500V maximizes solar energy harvest, enhancing battery life and system efficiency under varying sunlight conditions.

Up to 9 Units in Parallel Connection

Supports up to 9 units in parallel, operating in single-phase or three-phase modes. Expandable system design allows high-capacity setups, providing reliable power for large loads and scalable energy solutions without complex rewiring.

Advanced System Protection

Comprehensive safeguards protect against overvoltage, undervoltage, overcurrent, short circuit, and overheating. RS232 and RS485 communication ensures seamless monitoring and reliable operation for stable energy supply and long-term durability.

Flexible Output and Charging

Two output modes (SUB, SBU) and three charging strategies (solar first, hybrid, solar only) offer versatile energy management, optimizing battery charging and usage according to energy availability, load demand, and user preferences.

Especificaciones

Modelo

POW-HVM6.5KP

Potencia de carga nominal (W)

6500

Salida CA (V)

220 (±5% Adjustable)

Salida CC (V)

48

Fase

Single Phase, Three Phase (in Parallel Connection)

Preguntas Frecuentes

Can the 6.5kW solar inverter be used in a three-phase system with parallel connections?

Yes, the 6.5kW solar inverter is designed to support three-phase systems through parallel connections. It is required to have at least 3 inverters or maximum 9 inverters to support three phase equipment. It's required to have at least one inverter in each phase or it's up to four.

Can I mix different solar panel models with this inverter?

It is highly discouraged for panels on the same MPPT input string. Using panels of different make, model, or wattage on the same MPPT input string is strongly discouraged. All panels in a series string should be identical to prevent significant power loss, as output is limited by the lowest-performing panel. For mixed panels, use an inverter with separate MPPT inputs or parallel operation capability.

¿Cuál es el orden correcto para conectar mi sistema solar?

Al instalar un sistema de energía solar, conecte los componentes en este orden:
1) Baterías,
2) Controlador de carga/cargador inversor
3) Paneles solares (a la entrada PV)
4) Cargas del inversor/CA
Siempre verifique la polaridad, los voltajes y el tamaño de los cables para seguridad.
Al desconectar, invierta el orden.
