| Models | MPPT-60A | |
| Charging Model | 3-stage: Constant Current(MPPT), Constant Voltage, Floating | |
| MAX PV Input Power | 12V System | 720W |
| 24V System | 1440W | |
| 36V System | 2100W | |
| 48V System | 2800W | |
| Input Specification DC | 12V System DC | 20V-80V |
| 24V System DC | 37V-105V | |
| 36V System DC | 50V-160V | |
| 48V System DC | 72V-160V | |
| Battery Voltage Automatic Recognition: 12V Battery | DC 9V - DC 15V | |
| Battery Voltage Automatic Recognition: 24V Battery | DC 18V - DC 29V | |
| Battery Voltage Automatic Recognition: 36V Battery | DC 30V - DC 39V | |
| Battery Voltage Automatic Recognition: 48V Battery | DC 40V - DC 60V | |
| Overcharging Protection Voltage | 60V | |
| Limited Current Protection | 61A | |
| Max Efficiency | ≥98.1% | |
| PV Utilization | ≥99% | |
| Protection Function | ||
| Temperature Protection | 75℃ | |
| Fan-On Temperature | ＞45℃ | |
| Fan-Off Temperature | ＜40℃ | |
| Properties | ||
| Size(mm) | 214×115×50 | |
| Net Weight(Kg) | 1.1 | |
| Gross Weight(Kg) | 1.2 | |
| Electromagnetic Compatibility | Accord To EN61000, EN55022, EN55024 | |
| Enclosure | IP21 | |
| Environmental Temperature | -20℃~+55℃ | |
| Storage Temperature | -40℃~+75℃ | |
| |
|
|
|
|---|---|---|---|
Cooling FanIntelligence Fan-on temperature >45℃ and off < 40℃, let your controller feel cooling. |
Wiring portsIt is better to connect two wires to two PV+ and another two wires to two PV-. it’s the same way to connect battery BAT+ and BAT- wires. (you can use Y connector) |
Copper coinsThe Three copper coils play step-down roles in making your system work more stable. |
TransformerHigh-quality components, perfecting system performance, with a maximum conversion efficiency of 98% Three Electronic transformers, safer |
 |  |
NoteAir circuit breaker and wires requirement copper wires: 9AWG / air circuit: 100A Notes: The output terminal is for lamp only (12V system less 60W, 24V/36V/48V system less 100W ), and it will be burnt if connected to other loads. The output for the battery is no polarity reverse protection. | Package1*60a MPPT solar charge controller 1*User manual 4* Mountings |
1. The maximum PV input voltage (Voc): DC160V (The controller can’t work at this voltage of long duration that will break the controller. Please refer to the Input voltage from PV ).
2. The output terminal is for lamps only (12V system less 60W, 24V/36V/48V system less 100W ), which will be burnt if connected to other loads. The output for the battery is no polarity reverse protection.
3. Always connect the battery first!!! Make sure enough batteries’ voltage let the controller recognize the right system voltage. The disassembly sequence is contrary to the wiring order.
4. DO NOT connect any Inverter/ wind/ Alternator or Charger to the controller, please click the Inverter to the battery side.
5. Ensures solar input voltage higher than 3V or more than batteries’ voltage and total input power do not exceed the max. , the charging current almost be zero when the controller is floating charge.
mppt solar charge controller Cara Setting MPPT PowMr agar dapat watt peak
Di vidio ini akan dijelaskan Cara Setting MPPT PowMr agar dapat watt peak
secara detail dan step by step.
Your rivals that rank higher than you in the Google top 10 for some of your target keywords are using video content. Try to embed a video on your page.
Обзор MPPT контроллера PowMR 60A
Пришла посылочка с мппт контроллером, распаковка и обзор.
Unboxing dan Mudah setting SCC MPPT PowMr 60A
Unboxing, juga mudah setting SCC MPPT PowMr 60A step by step.
Ada banyak SCC yang dijual dengan harga bervariasi dan saya pilih PowMr 60A karena ekonomis dan sudah banyak yang menggunakannya juga.
| Question: | Does this unit have protection from power being input from alternate source on the output from this solar charge controller? |
| Answer: | This Controller MULTIPLE ELECTRONIC PROTECTIONS:Short-circuting,Reverse current,Overcharging,Overload,Over-discharging,Reverse polarity protection |
| Question: | Could i use 110v battery charger on battery with battery connected to charge controller? |
| Answer: | Hi dear customer,Best not to use at the same time |
| Question: | Is this unit wifi compatible? |
| Answer: | Hi dear customer, sorry, this controller is not wifi compatible. |
| Question: | If batteries wired 12v, does that mean pure sine wave inverter will accept 720watts from this charge controller? And if batteries are 24v, then 1440w? |
| Answer: | Hi dear customer,The inverter will not receive power from the solar panel, and the controller will supply power to the battery. Most of this power enters the battery and will not be directly supplied to the inverter. |
| Question: | Can you charge AGM battery with it? |
| Answer: | Hi dear customer, yes, this controller can charge AGM battery. |
| Question: | with this, i can charge 12.8V lifepo4 with 57V solar panels? panels batteries don't have to match voltage, correct? |
| Answer: | YES. |
| Question: | Can this product be used to charge LiFePO4 |
| Answer: | YES. |
| Question: | Can the overcharge protection voltage be customized? For example, can the overcharge protection voltage for a 12V system be made lower than 15V? |
| Answer: | HI dear customer,Is not possible because this parameter is the default, But our controller is connected to a 12V battery, the overcharge protection voltage is lower than 15V |
